CAMERA SPEC OF CLOSE-UP CAMERA
Sensor 1/2.7", CMOS, Effective pixel:8.29 Megapixels
Scanning Mode Progressive
Type of Lens Mount M12
Student Close-up Lens f=7.37mm, Horizontal FOV: 43°
Teacher Close-up Lens f=13.1mm, Horizontal FOV: 25°
Digital Zoom 2x
Minimum Illumination 0.5Lux
Shutter 1/30s ~ 1/10000s
White Balance Auto, Indoor, Outdoor, One Push, Manual, VAR
Digital Noise Reduction 2D&3D Digital Noise Reduction
Backlight Compensation Support
Pan Angle ±40°
Tilt Angle +5° ~ -30°
Maximum Rotation Speed
Student Camera: Pan Speed 60°/s,Tilt Speed 30°/s
Teacher Camera: Pan Speed 30°/s,Tilt Speed 30°/s
Image Flip Support
Image Freeze Support
Preset Position 255
Preset Accuracy 0.5°
CAMERA SPEC OF PANORAMIC CAMERA
Sensor 1/2.7", CMOS, Effective pixel:4.93 Megapixels
Scanning Mode Progressive
Type of Lens Mount M12
Student Panoramic lens f=2.2mm, Horizontal FOV: 110°
Teacher Panoramic lens f=7.37mm, Horizontal FOV: 43°
Minimum Illumination 0.5Lux
Shutter 1/30s ~ 1/10000s
White Balance Auto, Indoor, Outdoor, One Push, Manual, VAR
Digital Noise Reduction 2D&3D Digital Noise Reduction
Backlight Compensation Support
Tilt Angle +0° ~ -24°
Image Flip Support
Image Freeze Support
AUDIO
Simulation Audio Input 1 x LINE In
Simulation Audio Output 1 x LINE Out
Digital Audio Interface
1 x USB audio input output
1 x network audio input output, supports
1588-based audio clock synchronization
USB SPEC
Operating System Supported
Windows® 7 ( Only support 1080P and below ),
Windows 8.1 and above version;
macOS ™ 10.10 and above version;
Google ™ Chromebook ™ Version 29.0.1547.70 and above version;
Linux ( Need to support UVC)
Hardware Requirements
2.4 GHz Intel® Core 2 DUO processor or higher;
2 GB memory or higher;
USB 3.0 or USB 2.0 interface
Color System / Compression YUY2/MJPEG/H.264
Video Format Maximum 4K and other different frame rates and resolution video formats
USB Video Communication Protocol UVC 1.1
USB Audio The maximum 48K sampling rate, supports UAC1.0
UVC PTZ Control Support
NETWORK SPEC
Video Compression H.265 / H.264 / MJPEG
Video Stream First Stream, Second Stream, Third Stream, Fourth Stream
First Stream Resolution 3840x2160,1920x1080, 1280X720, etc.
Second Stream Resolution 2880x1620, 1920x1080, 1280X720, etc.
Third Stream Resolution 1920X1080,1280X720,1024x576, etc.
Fourth Stream Resolution 1920x1080, 1280x720,1024x576, etc.
Video Bit Rate 32Kbps ~ 16384Kbps
Bit Rate Type VBR, CBR
Frame Rate 25/30fps
Audio Compression AAC/G.711A
Audio Bit Rate 96Kbps, 128Kbps, 256Kbps
Support Protocols TCP/IP, HTTP, HTTPS, NDI, SRT, RTSP, RTMP, Onvif, DHCP, GB28181, Multicast, etc.
I / O
USB Interface 1x USB 3.0; Type-C
Network Interface 1 x RJ45: 10M / 100M adaptive Ethernet; PoE(802.3af), Support NDI¹
Audio Interface 1 x LINE In: 3.5mm, 1 x LINE Out: 3.5mm
Power Interface DC005 (DC 12V)
Reset Button RESET
Infrared Interface¹ Support
Indicator Light POWER ,STANDBY
